Jinko Tiger Pro 72HC-BDVP
Jinko Tiger Pro 72HC-BDVP
Model NO:72HC-BDVP 535-555 Watt
Cell Type: P-type Mono-crystalline
Weight:31 kg
Transport Package:Wooden Pallet and Carton Packing
Specification:2278*1134*30mm
Trademark:Jinko solar
Origin:China
CONTACT US
MESSAGE


MECHANICAL DATA
Cell Type P-type Mono-crystalline
No. of Cells144(6*24)
Dimensions2278*1134*30 mm
Weight31 kg
Front Glass2.0 mm, Anti-reflection Coating
Back Glass2.0 mm, Heat Strengthened Glass
FrameAnodized aluminium alloy
J-BoxIP68 rated
Output CablesTUV1 *4.0 mm (+): 400 mm, (-): 200 mm or Customized Length

ELECTRICAL DATE(STC)
Nominal Max. Power (Pmax)535w540w545w550w555w
Power Tolerance0~±3%
Opt. Operating Voltage (Vmp)40.9441.1341.3241.5141.7
Opt. Operating Current (Imp)13.0713.1313.1913.2513.31
Open Circuit Voltage (Voc)49.5449.7349.9250.1350.3
Short Circuit Current (Isc)13.8313.8913.9514.0114.07
Module Efficiency20.71%20.90%21.10%21.29%21.48%
